Product Introduction:
(1) The ultrasonic spray cleaning machine is mainly designed for cleaning SMT mesh boards in the electronics industry using water-based cleaning liquids.
(2) Using advanced cleaning techniques to achieve 100% cleanliness and environmental protection.
(3) The equipment consists of a rack, sprinkler system, ultrasonic system, rinsing system, lifting mechanism, drying system, and water circulation filtration system.
(4) The equipment is mainly powered by electricity, and the mesh board is manually placed in the cleaning room. After setting the spray, ultrasonic, drying and other related parameters in the touch screen, the start button is pressed, and the mesh board will be automatically sprayed, ultrasonic cleaned, rinsed and dried.
(5) Automatically stop running and reset after the set cleaning process is completed, in order to achieve the next workflow.
(6) The equipment is very convenient for operators to clean the mesh board, greatly improving production efficiency and quality It belongs to a new type of high-performance fully automatic cleaning equipment. The auxiliary consumables used in the equipment are water and water-based environmentally friendly cleaning agents, which have no safety hazards and pose no harm to personnel.
Product parameters:
| Project | FM40U |
| Machine dimensions (mm) | L1300mm*W850mm*H2130mm |
| Maximum cleaning range | 740mmX740mmX40mm |
| Cleaning solution tank capacity | 30L |
| Rinse water tank capacity | 30L |
| Gas source pressure | 0.5-0.7Mpa |
| Spray pressure | 0.15-0.3Mpa |
| Maximum power | 10KW |
| Voltage/Frequency | 380V/50HZ |
| Ultrasonic power/frequency | 1.5KW/40KHZ |
| Equipment weight | 400KG |
| Recommended cleaning agents | Water based cleaning agent |
Application case:
Steel mesh and mesh board suitable for SMT
FAQ:
1.Will you provide on-site support?
Our team of qualified and experienced engineers can provide on-site maintenance and repair support. You can use the online chat box Skype、Whatsapp、 Contact us by phone and email, and we are always on standby to assist you in resolving any issues.
2.Will any training be provided?
We provide a complete training program for all industrial testing equipment, maintenance equipment, picking and placing equipment, reflow soldering equipment, wave soldering, selective soldering equipment, solder paste printing machines, PCB splitting machines and other SMT production line equipment in our Shenzhen factory, and offer on-site training at the customer's location. Our plan aims to provide your engineers, technicians, and machine operators with the necessary knowledge to fully utilize the operation and maintenance of our machines.
3.Where can I buy spare parts?
You can visit our spare parts store to obtain the parts you need, which can be paid by bank transfer/PayPal/credit card. In addition, you can contact us to obtain parts and make payment through bank transfer.
H.F.X - Our Company
About H.F.X:
H.F.X is a leading provider of factory planning solutions and industrial inspection solutions. We have 4 wholly-owned factories that provide professional consulting and services to global customers. We have over 11 years of experience in electronic integrated solutions and industrial testing solutions. We not only provide a complete set of equipment, but also offer comprehensive technical support and services, and provide customers with more reasonable professional advice. We help many clients establish factories in LED, TV, mobile phone, DVB, EMS, and other industries around the world. We will establish factories in LED, TV, mobile phone, DVB, EMS, and other industries around the world. We are trustworthy.
Exhibition：
For SMT factory setup and industrial non-destructive testing, we can provide you with:
1.We provide you with complete SMT solutions and industrial testing solutions
2. We Provide Core Technology With Our Equipments
3. We provide the most professional technical services
4.We have rich experience in establishing SMT factories and industrial testing
5. We can solve any problems related to SMT and industrial testing
H.F.X-FM-40U | Ultrasonic Steel Mesh Cleaning Machine
