Detectable foreign objects and application industries
1. Types of detectable foreign objects:
Metals: all metals such as iron, copper, aluminum, stainless steel, etc.
Minerals: glass fragments, ceramics, stones.
High density plastic/rubber: PVC, PS, rubber blocks, etc.
Bones and shells: avian bones, fish bones, shell fragments.
Product defects: internal bubbles, cracks, missing materials/parts.
2. Typical application industries and products:
Meat and poultry processing: ham, sausages, meat patties, frozen chicken, etc.
Aquatic processing: fish fillet, shrimp, crab meat sticks, etc.
Leisure foods: potato chips, candy, chocolate, cookies, nuts.
Baking pastry: bread, cake, mooncake, filling.
Dairy products: cheese, butter chunks.
Fruits and vegetables: frozen vegetables, canned fruits.
Core strengths
1. Ultra wide detection window: 600mm x 350mm, perfectly compatible with various packaging and bulk product lines.
2. Overweight carrying capacity: Imported high-power servo motors are selected, with a conveying weight of up to 30KG carrying capacity.
3. Top hardware configuration: Using VJ Technologies high-frequency constant voltage X-ray generator from the United States and DT (Detection Technology) high-resolution linear array detector from Finland to ensure clear and stable images.
4. Efficient detection capability: The belt speed is infinitely adjustable from 20-75 meters per minute, balancing detection accuracy and production efficiency.
5. Intelligent recognition software: Advanced AI image processing algorithms effectively distinguish products from foreign objects, significantly reducing false alarm rates.
Core Configuration and Technical Highlights
1. Powerful X-ray emission system
Brand: VJ Technologies, USA
Features: High frequency constant voltage technology, good radiation quality, strong penetration, low power consumption, long lifespan. Stable power ensures optimal imaging results at different product densities, laying a solid foundation for high-precision detection.
2. High precision image acquisition system
Brand: Finland DT 0.4mm (Detection Technology) linear array detector
Features: High resolution, high sensitivity, low noise. Capable of capturing extremely subtle density differences, even tiny foreign objects embedded inside the product or placed at the bottom of the packaging have nowhere to hide.
3. Advanced image processing software
Multi algorithm recognition: Integrating multiple algorithms such as region detection, morphological analysis, and pattern recognition, it can accurately recognize the shape and material of various foreign objects.
Product learning function: It has powerful product library management function, can store multiple product parameters, and can be called with one click when changing production, which is simple and fast.
Automatic removal synchronization: The software intelligently calculates the position of foreign objects and belt speed, and instructs the removal device to operate accurately within milliseconds to ensure error free removal.
User friendly interface: Full Chinese touch screen operation interface, simple settings, strong visualization, and operators can get started after simple training.
4. Sturdy and hygienic mechanical structure
Detection window size: 600mm (width) × 350mm (height), suitable for boxed, bagged, framed, bottled, and palletized products.
Rack material: Made of high-quality stainless steel (such as 304 or 316L), which meets the hygiene standards of the food industry and is easy to clean and disinfect.
Conveyor belt system: food grade PU or PVC belt, with a speed of 20-75 meters per minute that can be infinitely adjusted to meet different production cycle requirements.
Safety protection: Comprehensive lead curtain protection, in compliance with international radiation safety standards; Equipped with a door lock safety switch, the power automatically shuts off upon opening the door, ensuring absolute safety for operators.
Technical Specifications
| Project | Parameter |
| Model | SPX-200 |
| Detection accuracy | 0.3mm (metal ball)/0.2 * 2mm (metal wire)/0.6mm (ceramic, stone)/0.8mm (glass) |
| Channel size | 400mm (width) × 250mm (height) |
| Detection speed | 20-75 meters/minute (adjustable) |
| X-ray light source | VJ 210W 80KV from the United States |
| Detector | Finnish DT X-Scan C 0.2mm linear array detector |
| Protection standards | Radiation leakage<1 μ Sv/h (compliant with national standards) |
| Software system | AI intelligent recognition+data tracing |
| Software features | Foreign object detection, weight sorting, missing parts detection, shape defect recognition, data statistics |
| Operating system | Windows 11 |
| Conveying weight | 30KG |
| Display screen | 17 inch full-color touch screen |
| Whole machine material | 304 stainless steel |
| Light source temperature adjustment | Industrial air conditioning automatic constant temperature/air cooling |
| Operation method | Touch screen operation |
| Support data interface | LAN port，USB port |
| Product Management | Complete product log |
| Parameter adjustment | Self learning/manual learning optional |
| Image management | Image saving/printing/analysis |
| Body material | SUS304 |
| Protection method | Detachable protective curtain/cover |
| Environmental temperature/humidity | 0~40 ° C/30~90%, no frost formation |
| Protection level | IP65 |
| Belt direction | Available from left to right/right to left |
| Elimination method | Swing rod/push plate removal/flipping/blowing air (optional) |
| Belt to ground height | 750+100mm (height can be customized and matched according to the assembly line) |
| Overall dimensions of the equipment | Length x width x height: 1650x530x1895 mm |
| Power requirements | AC 110-220V, 50/60Hz (customizable) |
The value we offer you
1. Improve food safety: eliminate complaints about foreign objects and protect consumer safety.
2. Maintain brand reputation: Avoid brand crises and recall losses caused by product quality issues.
3. Comply with regulatory requirements: easily pass various food safety audits and certifications at home and abroad.
4. Improve production efficiency: automate testing, reduce labor costs, and achieve 100% online full inspection.
5. Reduce overall costs: preventive quality control, far lower than the cost of post recall and brand loss.
6. Comprehensive after-sales service: providing professional installation, debugging, training, and quick after-sales response.
